Haupt-Spezifikationen
Herstellergarantie
3 Jahre Garantie
Stromversorgung
Wechselstrom 230 V
Produktzertifizierungen
IEEE 802.1Q, IEEE 802.3af, IEEE 802.3az
Leistungsmerkmale
IGMP Snooping, MLD-Snooping, SPI, Paketfilterung, Port-Weiterleitung, Traffic Shaping, Bandbreitensteuerung, DiffServ-Unterstützung, ToS, ACL Support, DoS protection, IPS, IP-Spoofing, Passwortschutz, Stealth Mode, URL-Blocker, Analog-/GSM-Modem Backup, IPv4 und IPv6 Dual-Stack, ARF, HTTP-Server, DNS-Klient, DNS-Server, DNS-Relais, DNS proxy, dynamischer DNS-Client, DHCP-Client, DHCP-Relais, DHCP-Server, NetBIOS/IP-Proxy, NTP-Klient, SNTP-Server, Bonjour-Proxy, DHCPv6 Client, DHCPv6 Server, NDP, SLAAC, Syslog-Unterstützung, E-Mail-Meldung, SNMP-Trap, FirmSafe, Receiver Diversity, NetFlow, Sicherheitsslot (kompatibel mit Kensington Slot), LANCOM Management Cloud
Remoteverwaltungsprotokoll
HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3, TFTP, SSH, Telnet
Routing Protocol
VRRP, Policy-Based Routing (PBR), RIP-2, IGMPv3, MLDv2
Netzwerk/Transportprotokoll
IPv4, IPv6, DNS, ICMP/IP, NTP, PPPoE, RTP, DHCPv6
Kapazität
Virtuelle Schnittstellen (VLANs): 4096
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Mobilfunk-Frequenzband
5G n1, 5G n2, 5G n3, 5G n5, 5G n7, 5G n8, 5G n12, 5G n13, 5G n14, 5G n18, 5G n20, 5G n25, 5G n26, 5G n28, 5G n29, 5G n30, 5G n38, 5G n40, 5G n41, 5G n48, 5G n66, 5g n70, 5G n71, 5G n75, 5G n76, 5G n77, 5G n78, 5G n79, LTE B1, LTE B2, LTE B3, LTE B4, LTE B5, LTE B7, LTE B8, LTE B12, LTE B13, LTE B14, LTE B17, LTE B18, LTE B19, LTE B20, LTE B25, LTE B26, LTE B28, LTE B29, LTE B30, LTE B32, LTE B34, LTE B38, LTE B39, LTE B40, LTE B41, LTE B42, LTE B43, LTE B48, LTE B66, LTE B71, UMTS B1, UMTS B2, UMTS B4, UMTS B5, UMTS B8, UMTS B19
Zellprotokoll
LTE, UMTS, HSPA
Gehäusetyp
Wandmontierbar
Netzwerk
Anschlusstechnik
Kabelgebunden
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Formfaktor
Wandmontierbar
Netzwerk/Transportprotokoll
IPv4, IPv6, NTP, DNS, ICMP/IP, RTP, DHCPv6, PPPoE
Remoteverwaltungsprotokoll
SNMP 1, HTTPS, TFTP, SSH, Telnet, SNMP 3, SNMP 2c, HTTP
Routing Protocol
Policy-Based Routing (PBR), MLDv2, RIP-2, VRRP, IGMPv3
