Haupt-Spezifikationen
Stromversorgung
DC 48 - 56 V
Produktzertifizierungen
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, ITU-T G.8032, IEEE 802.3ag
Leistungsmerkmale
Flusskontrolle, Auto-Negotiation, BOOTP-Unterstützung, Auto-Uplink (Auto MDI/MDI-X), IGMP Snooping, Syslog-Unterstützung, Port-Spiegelung, Store-and-Forward, Broadcast Storm Control, Halbduplex-Modus, Vollduplex-Modus, Multicast Storm Control, Unicast Storm Control, Firmware aktualisierbar, STP Support, RSTP-Unterstützung, MSTP Support, DHCP-Snooping, ACL Support, QoS, MLD-Snooping, DAI, Reset-Taste, Bandbreitensteuerung, LLDP-Support, DHCP-Relais, Portkonfiguration, SNMP-Trap, MVR, CoS, gekennzeichnetes VLAN, 6KV ESD Protector, GVRP, PSE, PTP, ERPS, protokollbasierter VLAN-Support, Systemprotokoll, IP-Quellwächter, Back Pressure Support, Link Aggregation, IGMP Abfrager, Voice VLAN, PVE, DSCP Marking, WRR, MAC based VLAN, DSPC/TOS Feld in IP-Paket, BPDU Guard, Q-in-Q Tunneling, Port-Deaktivierung, Aluminiumgehäuse, MLD-Abfrager, NTP-Unterstützung, SMTP-Benachrichtigungen, UDLD
Remoteverwaltungsprotokoll
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, SSH, CLI
Routing Protocol
IGMPv2, IGMP, OSPFv2, IGMPv3, statisches IPv4-Routing, statisches IPv6-Routing, MLDv2, MLD
Jumbo-Rahmenunterstützung
10KB
Größe der MAC-Adresstabelle
32.000 Einträge
Kapazität
VLAN-Gruppen: 4000 ¦ VLAN IDs: 4094 ¦ Multicast-Gruppen: 255 ¦ ACL-Einträge: 512 ¦ Virtuelle Schnittstellen (VLANs): 128 ¦ Übertragungseinträge: 128
Leistung
Switching Fabric-Bandbreite: 66 Gbit/s ¦ Durchsatz (64-Byte Paketgröße): 49,107 Mpps
Power Over Ethernet (PoE)
PoE+
Ports
8 x 10/100/1000 (PoE+) + 2 x SFP + 2 x 10 Gigabit SFP+
Untertyp
Gigabit Ethernet
Netzwerk
Advanced Switching
Layer 3
Formfaktor
An DIN-Schiene montierbar, Wandmontierbar
Jumbo-Rahmenunterstützung
10KB
Power Over Ethernet (PoE)
PoE+
Remoteverwaltungsprotokoll
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SSH, CLI, Telnet, SNMP 3, SNMP 2c, HTTP
Routing Protocol
Statisches IPv4-Routing, Statisches IPv6-Routing, MLDv2, MLD, IGMPv2, IGMP, OSPFv2, IGMPv3
Unterkategorie
Netzwerk-Hubs und Switches
Untertyp
Gigabit Ethernet
