Haupt-Spezifikationen
Redundante Stromversorgung
Ja
Stromversorgung
DC 48 - 56 V
Produktzertifizierungen
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
Leistungsmerkmale
DHCP Support, BOOTP-Unterstützung, VLAN-Unterstützung, Auto-Uplink (Auto MDI/MDI-X), IGMP Snooping, Port-Spiegelung, E-Mail-Meldung, Weighted Round Robin (WRR) Queuing, Store-and-Forward, Broadcast Storm Control, IPv6-Unterstützung, Halbduplex-Modus, Vollduplex-Modus, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) Support, unterstützt Rapid Spanning Tree Protocol (RSTP), Multiple Spanning Tree Protocol (MSTP) Support, DHCP-Snooping, Access Control List (ACL) Support, Quality of Service (QoS), IP Precedence, Cable Diagnostics Function, Bandbreitensteuerung, IPv4-Unterstützung, LLDP-Support, DHCP-Relais, Link Aggregation Control Protocol (LACP), Multicast VLAN Registration (MVR), Verhindern von Schleifenbildung, Class of Service (CoS), 6KV ESD Protector, Type of Service (ToS), unterstützt DiffServ Code Point (DSCP), Ethernet Ring Protection Switching (ERPS), protokollbasierter VLAN-Support, IP-Quellwächter, ARP-Inspektion, Bridge protocol data unit (BPDU), Digital Diagnostics Monitoring (DDM), Network Timing Protocol (NTP), VLAN Double Tagging (Q-in-Q)
Remoteverwaltungsprotokoll
SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, TFTP, SSH
Routing Protocol
IGMPv2, IGMP, IGMPv3, MLDv2, MLD
Jumbo-Rahmenunterstützung
9KB
Kapazität
ACL-Einträge: 123 ¦ Einträge in Routingtabelle: 32
Leistung
Switching Fabric-Bandbreite: 40 Gbit/s ¦ Durchsatz (64-Byte Paketgröße): 29,7 Mpps
Power Over Ethernet (PoE)
PoE+
Ports
16 x 10/100/1000 (PoE+) + 2 x 10/100/1000 + 2 x SFP
Untertyp
Gigabit Ethernet
Netzwerk
Advanced Switching
Layer 3
Formfaktor
An DIN-Schiene montierbar, Wandmontierbar
Jumbo-Rahmenunterstützung
9KB
Power Over Ethernet (PoE)
PoE+
Remoteverwaltungsprotokoll
SNMP 1, SNMP 2, TFTP, SSH, Telnet, SNMP 3, HTTP
Routing Protocol
MLDv2, MLD, IGMPv2, IGMP, IGMPv3
Unterkategorie
Netzwerk-Hubs und Switches
Untertyp
Gigabit Ethernet
